MD-02

MDJ Fully Automatic Manipulator Palletizer

Short Description:

The application of robots in the palletizing of finished products has become more and more widely recognized by the market. It has advantages unmatched by other equipment. In recent years, the application of robots in developed countries such as Europe, America and Japan has exceeded 70%. At present, the domestic In addition, the robots mainly used in palletizing are: Sweden ABB, Germany KUKA, Japan FUJI ACE, FANUC, OKURA, KAWASAKI, etc.


Product Detail

benefits

Product Tags

The application of robots in the palletizing of finished products has become more and more widely recognized by the market. It has advantages unmatched by other equipment. In recent years, the application of robots in developed countries such as Europe, America and Japan has exceeded 70%. At present, the domestic In addition, the robots mainly used in palletizing are: Sweden ABB, Germany KUKA, Japan FUJI ACE, FANUC, OKURA, KAWASAKI, etc.

The palletizing robot is mainly designed for packaging applications. Although the body is small and can be integrated into a compact packaging machine, it can meet all your requirements in terms of reach and payload. Coupled with motion control and tracking performance, the robot is very suitable for use in flexible packaging systems, greatly shortening the packaging cycle time. With extremely high accuracy, coupled with excellent conveyor tracking performance, whether it is a fixed position operation or an operation in motion, its pick and place accuracy is first-class. Small size, fast speed, and optimized specifically for packaging applications, it is an inevitable choice for robot automation. Equipped with a full set of auxiliary equipment (from integrated air and signal system to grabber), packaging software can be used in conjunction, mechanical integration is simple, and programming is very convenient. In terms of efficiency, palletizing robots can not only bear high loads, but also speed and quality are much higher than those of manual labor.

At present, taking the four-axis handling robot as an example, it is divided into 100Kg-700Kg models according to the different load. It can reach a maximum speed of 2500mm/s in linear motion; the maximum handling capacity can reach 1600 times/hour. In terms of accuracy, each palletizing robot has an independent control system, which greatly guarantees the accuracy of the operation, and the repeatability can reach ±0.5mm, which can fully meet the positioning requirements of the logistics palletizing operation. Using the most advanced 4-axis design, a high-speed robot with a reach distance of 3.15m and a payload of 250kg, it is very suitable for automatic stacking of materials in the form of bags, boxes, crates, bottles, etc. Suitable for harsh environment applications, the protection level reaches IP 67. The robot's versatility, reach distance and load-bearing capacity can meet almost any stacking application requirements.

Technical Parameter

machine model MD-X01J Robot Palletizer
Power supply / power 380V 50/60HZ 12KW
Payload 80kg-700kg ( Select a suitable robot model according to customer needs)
Applicable Products Cartons, turnover baskets, film-packed beverages, plastic drums, paper drums, iron drums, etc.
Palletizing speed 10-40 boxes / minute
Palletizing method Single box / multiple boxes
Use air source 6-7kg
Working radius 800mm-3150mm



2
1

FAQ

1. I did not find the machine exactly meet our requirements.
All our machine can be customer built to meet your special needs.

2. We are not sure what design can fit us best.
Our engineers can be your factory to work out the suitable design. We offer on-site service in your factory. Our service is from design to installation.

3. Do you offer training service?
We will instruct your operators, team leaders and electric engineers before delivery in our factory, or train them after installation in your factory. And it is free charges.

4.After-sale service.
Contact and telephone number is provided by us for 24 hours/7 days a week support. We will respond the help within 24 hours. Our engineers are available to service overseas if necessary.
